| Feature | Wil6800 |
| LUT | 5936 |
| Embedded memory (kbit) | 180 |
| Distributed RAM (kbit) | 47 |
| GPLL | 1 |
| D-PHY PLL | 2 |
| Embedded I2C block | 2 |
| Embedded Rx / TX Mipi d-phy | 2 (8 dtat+ 2 clock) |
| 48 MHz oscillator | 1 |
| 10 kHz oscillator | 1 |
| Configuration memory | Flash |
| Dual boot 1 | yes |
| Power management unit | yes |
| Low power sleep mode | yes |
| Power consumption during typical operation | 5 mW - 135 mW |
| package size | 2.9 mm x 2.9 mm |
| pin pitch | 0.4 mm |
| Programmable I / O | 14 |
| Built in PSRAM | 64Mbits |
| package | FO-CSP64 |
